1/4" Mini Air Regulator with Gauge – 3-Position Locking Knob, 25 SCFM, 250 PSI Max, 5–125 PSI Adjustment Range, Zinc Body
Made in USA

1/4" Mini Air Regulator with Gauge – 3-Position Locking Knob, 25 SCFM, 250 PSI Max, 5–125 PSI Adjustment Range, Zinc Body

$52.80 - $52.80
$52.80
$52.80 - $52.80
$52.80
SKU:

R162G

The Arrow Pneumatic 1/4" Mini Regulator with Gauge (Model MRG-14) provides compact yet highly accurate pressure control for small-to-medium air systems. Built with a durable zinc body, this mini regulator ensures dependable performance while offering a working pressure range of 5–125 PSI and supporting up to 250 PSI max inlet pressure.

Equipped with a 3-position, non-rising adjustment knob, the regulator allows users to pull to adjust, push to lock, or detach for tamper-resistant security—perfect for shared workspaces or industrial settings. The brass valve seat guarantees pressure stability, ensuring it won’t drift during operation.

This self-relieving regulator also helps maintain consistent downstream pressure by venting excess air automatically, protecting tools and maintaining optimal performance. The built-in gauge offers real-time pressure monitoring at a glance, while replaceable internal components make this unit a long-term solution that’s both serviceable and upgradeable.

Whether you're outfitting a workstation, tool bench, or industrial compressor line, this 1/4" mini air regulator offers durability, control, and safety in a compact, reliable package.

Product Features
  • Precise Pressure Regulation – Accurately adjusts compressed air output between 5–125 PSI to match specific tool or equipment requirements.
  • 3-Position Locking Control Knob – Features a non-rising knob with pull-to-adjust, push-to-lock, and detach-to-make-tamper-resistant settings for secure operation.
  • Durable Zinc Body with Gauge – Compact and rugged zinc construction with built-in pressure gauge provides long-lasting reliability in demanding environments.
  • Self-Relieving Design – Automatically vents excess downstream pressure for safe, consistent performance without overpressurizing tools.
  • Serviceable & Upgradeable – Includes replaceable internal parts, allowing for complete unit maintenance and extended service life.

SPECIFICATIONS

For use with: Compressed Air
NPT: 1/4"
Sintered Bronze Filter Element Size: na
Max Flow SCFM: 25
Knob Type: 3 position non rising
Pressure Gauge: Included
Gauge Port: 1/4"
Operating Temp Range (Degrees): 40°F to 120°F
Regulator -Adjustment Range: 5 to 125
Manufacturers Warranty: 1 yr
UOM: EA
Product Dimension: 1.5 in x 1.25 in x 2.75 in
Safety Compliance: R162G
ELT: N
UL: N
FM Approved: N
ISO 610 Compliance: N
CA Proo 65: Y
Hazard Material Flag: N
SDS Indicator: N
Ozone Depleting Compounds: N
Special Permit for any mode of Transport: N
Product a Marine Pollutant: N
Can Item be sold in all States: Y
Safety Data Sheets: N
Is item safe with electronical compontes: N
Does this prodcut operate by battery, solor or electricity: N
